AutoScan-DS-EX low cost lab scanner丨www.shining3ddental.com

· -The AutoScan-DS-EX consists of detachable modules enabling future functional upgrades
· -lnnovative quick release jig for convenient model setup

Not only is model placement easy and time-saving, the AutoScan DS-EX also offers high scanning efficiency that wll resutin higher productivtry.

Bite

13 s

1-8 Dies

30 s

Single Jaw

30 s

Impression

120 s

With the clinic mode, desktop 3D scanner can be applied to dental clinics directly to support chair-side restoration solutions.

Export STL data, high compatibility with current open CAD/CAM software and hardware in the market.

AutoScan-DS-EX Pro supports multiple dental scan applications, including wax-up, die, plaster model, impression, articulator and texture.

Camera resolution	1.3 mega pixel
Scanning Range	100 mm * 100 mm * 75 mm
Scanning Time	bite: 13 s; upper / lower jaw: 30 s; 1-8 dies: 30 s; impression: 120 s
Scanning Principle	structured light 3D scanning
Temperature	0° C - 30° C (higher temperature will affect the scanning result)
Dimension	260 mm * 270 mm * 420 mm
Weight	5 kg
Output Format	STL, OBJ
Interface	USB 3.0
Power	DC24 V
